Cameras For Printed Circuit Board Inspection And Defect Detection

Catch Every Defect With Ultra-High Resolution And Fast Interfaces

Ensure flawless electronics and PCB production with industrial cameras. Detect defects, improve quality control, and optimize your manufacturing processes.

Challenges & Trends

Semicon, Electronics & Display inspection

Detecting Every Assembly Error

Catch every misplacement or soldering defect in real time. Prevent costly rework and ensure every board meets quality standards.

Maintaining High Throughput Without Compromise

Keep inspections in step with fast production lines. Balance speed and precision to protect both yield and reliability.

Achieving Precise, Reliable Quality Assessments

Evaluate every PCB, even at submillimeter scale. Deliver consistent, flawless electronics while safeguarding production output.

Applications

Solder Paste Inspection

Inspection of applied solder paste to detect insufficient coverage, bridging, or misalignment before component placement.

Component Placement And Verification

Verify that all components are present, correctly oriented, and properly polarized before soldering.

Solder Joint Quality Control

Detect insufficient, excessive, or cold solder connections to guarantee reliable reflow results.

apllication PCB microchip 1181909730 (1)

Surface Defect and Damage Inspection

Spot scratches, cracks, contamination, or foreign particles on PCB surfaces before final assembly.

Circuit Trace Verification

Inspection of PCB traces and patterns to detect breaks, shorts, or deviations from design specifications.

Technical Requirements

High-resolution low-noise cameras detecting every defect on printed circuit boards
High-bandwidth and fast interfaces meeting increasing throughput and time pressure demands
Robust camera for clean room environments
Intelligent sensor alignment for more precision in electronics and PCB inspection

The Right Camera

Alvium G1-319

Alvium G1-319 with Sony IMX265 runs 37 frames per second at 3.2 MP resolution.

Compact industrial-grade housing
Established GigE Vision standard
Comprehensive feature set
Long-term availability and reliability
See Alvium G1 camera series

fxo547MCX

fxo547MCX with Sony IMX547LLA runs 124 frames per second at 5 MP resolution.

CoaXPress-12 interface, PoCXP
Thermally optimized aluminum housing
Extremely low Jitter
Integrated 4-channel LED strobe controller
See fxo camera series

fxo530CCX12-2C

fxo530CCX12-2C with Sony IMX530AAQJ runs 97.6 frames per second at 24.6 MP resolution.

CoaXPress-12 interface with 2 connections
Thermally optimized aluminum housing
Extremely low Jitter
Integrated 4-channel LED strobe controller
See fxo camera series
